ASUS TUF Gaming F16
Processor: Intel Core i7 Processor 14650HX 2.2 GHz
Memory: 16GB DDR5-5600 SO-DIMM
Stroage: 1TB PCIe 4.0 NVMe M.2 SSD
Screen: 16-inch FHD+ 16:10 (1920 x 1200, WUXGA) 165Hz
Graphics card: NVIDIA GeForce RTX 5060 Laptop GPU 8GB GDDR7
Operating System: Windows 11 Home
Processor
Intel Core i7 Processor 14650HX 2.2 GHz (30MB Cache, up to 5.2 GHz, 16 cores, 24 Threads)
Chipset
Mobile Intel HM770 Express Chipsets
DIMM Memory
16GB DDR5-5600 SO-DIMM, the memory speed of the systems vary by CPU SPEC
Total System Memory
DDR5 16GB
Memory Slot
2x SO-DIMM slots
Memory Max.
64GB
Multi-channel memory technology
Support dual channel memory technology
Storage
1TB PCIe 4.0 NVMe M.2 SSD
M.2 slots support either SATA or NVMe
2
M.2 SSD Support List
M.2 512GB PCIe SSD
M.2 1TB PCIe SSD
M.2 2TB PCIe SSD
Expansion Slot (includes used)
2x DDR5 SO-DIMM slots
2x M.2 PCIe
Panel Size
16-inch
Resolution
FHD+ 16:10 (1920 x 1200, WUXGA)
Refresh Rate
165Hz
Viewing Angle
85/85/85/85
Panel Tech
IPS-level
Graphic NVIDIA
GeForce RTX 5060 Laptop GPU
Graphic Wattage
115W (100W+15W)
Graphic Memory
8GB GDDR7
LAN
10/100/1000 Mbps
Wireless
Wi-Fi 6E(802.11ax) (Triple band) 2x2 + Bluetooth 5.3 Wireless Card (xBluetooth version may change with OS version different.)
I/O Ports
1x RJ45 LAN port
1x Thunderbolt 4 with support for DisplayPort / G-SYNC (data speed up to 40Gbps)
1x USB 3.2 Gen 2 Type-C with support for DisplayPort / power delivery (data speed up to 10Gbps)
3x USB 3.2 Gen 2 Type-A (data speed up to 10Gbps)
Display output
1x HDMI 2.1 FRL
Camera
1080P FHD IR Camera for Windows Hello
Mic
Built-in array microphone
Keyboard Type
Backlit Chiclet Keyboard 1-Zone RGB
With Copilot key
Speakers
2-speaker system
Audio
1x 3.5mm Combo Audio Jack
Built-in array microphone
Audio Tech
AI noise-canceling technology
Dolby Atmos
Hi-Res certification (for headphone)
Support Microsoft Cortana near field/far field (Microsoft service suspended in spring of 2023.)
Battery
90WHrs, 4S1P, 4-cell Li-ion
Power
Rectangle Conn, 280W AC Adapter, Output: 20V DC, 14A, 280W, Input: 100-240V AC, 50/60Hz universal
Required charging power
Min: 45W
Max: 100W
What's in the box
1x FX608JMR-I71610G0W
