Daikin Ceiling Cassette Air Conditioner 30000BTU Inverter with Drain Pump Mechanism, R32 FCVFQ90AV16/RZVFQ90AV16

Overview

The Daikin Ceiling Cassette Air Conditioner (30000BTU, Inverter, R32) delivers superior comfort with its 360° uniform airflow. Designed for commercial and large residential spaces, it combines advanced features like a Silver ION antibacterial system, a built-in drain pump, and energy monitoring for efficient, clean, and reliable climate control.

Key Features

• 360° Uniform Airflow for all-around comfort and even cooling/heating.
• Inverter Technology for energy efficiency and precise temperature control.
• Drain Pump Mechanism enables efficient condensate drainage for long pipe runs.
• Silver ION Antibacterial Drain Pan & Fan prevents bacteria, mould, odours, and clogging.
• D III Net Compatible for centralized control without an optional adaptor.
• Individual Air Flow Control allows adjustment of each air discharge outlet.
• Night Quiet Operation automatically reduces noise for undisturbed sleep.
• Swing Pattern Selection (Standard, Draft Prevention, Ceiling Soiling Prevention).
• Auto Restart function resumes operation automatically after a power cut.
• Energy Consumption Monitoring displays daily, weekly, and yearly power usage.
• Low Gas Pressure Detection for system protection.
• Optional Fresh Air Intake Kit compatibility.

Specifications

• Brand: Daikin
• Model: FCVFQ90AV16 / RZVFQ90AV16
• Type: Ceiling Cassette Air Conditioner
• Cooling Capacity: 30000 BTU (Rated: 9 kW, Range: 4.5~10.1 kW)
• Compressor: Inverter (Swing Compressor, 1 Nos.)
• Refrigerant: R-32
• Rated Power Input: 2820 Watts
• ISEER: 3.99 Wh/Wh
• Annual Power Consumption: 1745.56 kWh
• BEE Star Rating: 3-Star
• Operating Range (IDU/ODU): 19~35°C / 19~50°C
• Power Supply: 230V / 50Hz / 1 Phase
• Indoor Unit Size (HxWxD): 298 x 840 x 840 mm (Casing)
• Indoor Unit Weight: 25 kg (Casing), Panel: 5.5 kg (695x930x350 mm)
• Outdoor Unit Size (HxWxD): 595 x 845 x 300 mm
• Outdoor Unit Weight: 48 kg / 44 kg (Approx.)
• Color: White (Indoor Casing: Galvanized Steel Coated)
