Daikin Ceiling Cassette Air Conditioner 36000BTU Inverter with Drain Pump Mechanism, R32 FCVFQ100AV16/RZVFQ100AV16

Overview

The Daikin Ceiling Cassette Air Conditioner (36000BTU, Inverter, R32) delivers superior 360° uniform airflow for enhanced comfort. It integrates advanced features like a Silver ION antibacterial system, a built-in drain pump, and energy monitoring, all while offering quiet operation and flexible control for optimal air distribution in commercial or residential spaces.

Key Features

• 360° Uniform Airflow for all-around comfort and even cooling/heating.
• Inverter Technology for efficient and consistent temperature control.
• Silver ION Antibacterial Drain Pan & Fan prevents bacteria, mould, odours, and clogging for cleaner air.
• Built-in Drain Pump Mechanism for efficient condensate drainage, suitable for long piping runs.
• Individual Air Flow Control allows adjustment of each air discharge outlet for optimal distribution.
• Night Quiet Operation mode activates automatically for reduced noise levels.
• Swing Pattern Selection with Standard, Draft Prevention, and Ceiling Soiling Prevention settings.
• Energy Consumption Monitoring displays past usage (daily, weekly, yearly).
• Auto Restart function resumes previous operation after a power cut.
• D III Net Compatible for centralized control without an optional adaptor.
• Low Gas Pressure Detection for system protection.
• Fresh Air Intake Kit compatible (optional).

Specifications

• Brand: Daikin
• Model: FCVFQ100AV16 / RZVFQ100AV16
• Type: Ceiling Cassette Air Conditioner
• Cooling Capacity: 36000 BTU (10.5 kW Rated)
• Capacity Range (Min~Max): 5.0 kW ~ 10.5 kW
• Compressor: Inverter (Swing Compressor, 1 Nos.)
• Refrigerant: R-32
• Rated Power Input: 3430 Watt
• ISEER: 3.66 Wh/Wh
• Annual Power Consumption: 2221.32 kWh
• BEE Star Rating: 3-Star
• Operating Range (Indoor/Outdoor): 19~35°C DB / 19~50°C DB
• Power Supply: 230V / 50Hz / 1 Phase
• Indoor Unit Size (HxWxD): 298 x 840 x 840 mm (Casing)
• Indoor Panel Size (HxWxD): 50 x 950 x 950 mm
• Indoor Unit Weight: 25 kg (Casing: 25kg, Panel: 5.5kg)
• Outdoor Unit Size (HxWxD): 695 x 930 x 350 mm
• Outdoor Unit Weight: 48 kg
