EZVIZ B1 4-Piece Home Security Alarm Sensor Kit

Kit Components

• A3 Home Gateway (central control hub)

• T1C PIR Motion Sensor

• T2C Door/Window Contact Sensor

• T3C Smart Button

A3 Home Gateway

• Model: CS-A3

• Power Input: DC 5V/1A (via micro-USB or Type-C)

• Max Power Consumption: 3W

• Connectivity: Ethernet (RJ45), Wi-Fi 2.4GHz, ZigBee 3.0, Bluetooth 5.3

• Device Support: Up to 64 connected devices (32 battery-powered max)

• Operating Temperature: -10°C to 55°C

• Operating Humidity: ≤95% (non-condensing)

• Dimensions: 70mm (diameter) × 25mm (height)

• Weight: 71g

T1C PIR Motion Sensor

• Type: Passive Infrared (PIR)

• Detection Range: Up to 7 meters

• Detection Angle: 90° horizontal and vertical

• Pet Immunity: Optional shield included

• Battery: CR2450 (approx. 1–2 years lifespan)

• Connectivity: ZigBee 3.0

• Mounting: Peel-and-stick or magnetic

• Operating Temperature: -10°C to 55°C

• Humidity: ≤95%

• Dimensions: 43.5mm × 32mm (sensor), 29mm × 9.5mm (base)

• Weight (with package): ~92g

T2C Door/Window Sensor

• Type: Magnetic contact sensor

• Trigger Distance: 25mm (wood), 15mm (metal)

• Battery: 2 × CR1632 (approx. 2 years with 30 triggers/day)

• Connectivity: ZigBee 3.0

• Mounting: Peel-and-stick

• Operating Temperature: -10°C to 55°C

• Humidity: ≤95%

• Dimensions: 53.5 × 22.5 × 13.5 mm (main), 32 × 10.5 × 13.5 mm (magnet)

• Weight (with package): ~80g

T3C Smart Button

• Functionality: Single press (Arm/Disarm), Long press >2s (Emergency alert or custom actions)

• Battery: CR2032 (up to 2 years, ~15 presses/day)

• Connectivity: ZigBee 3.0

• Mounting: Portable or adhesive

• Operating Temperature: -10°C to 55°C

• Humidity: ≤95%

• Dimensions: 40.6mm (diameter) × 12.3mm (height)

• Weight (with package): ~68g

Smart Features

• Control and notifications via EZVIZ App

• Triggers auto-recording on linked EZVIZ cameras

• Voice Assistant Support: Google Assistant, Amazon Alexa, Apple HomeKit, and Matter

• Easy installation with adhesive mounts

In the Box

• A3 Home Gateway with power adapter and USB cable

• T1C Motion Sensor with pet shield

• T2C Door/Window Sensor

• T3C Smart Button

• Adhesive tape strips

• Quick Start Guide and Warranty Info
