DJI BS100 Intelligent Battery Station

DJI BS100 Intelligent Battery Station – Product Overview

Designed for professional drone operators and enterprise fleets, the DJI BS100 Intelligent Battery Station delivers high-speed, automated charging with advanced battery health management. Engineered to maximize uptime and extend battery lifespan, this station is the backbone of any demanding aerial workflow.

Key Features

• Ultra-Fast Charging: Simultaneously charges up to 8 batteries with a total power output of 1000W, reducing turnaround time by up to 50%.
• Intelligent Battery Care: Integrated smart algorithms monitor temperature, voltage, and cycle count to prevent overcharging and thermal stress.
• Modular & Scalable Design: Stackable units allow seamless expansion for large fleets, with hot-swappable battery trays for uninterrupted operations.
• Dual-Mode Operation: Supports AC mains power and optional DC input (solar/generator) for field deployment.
• Real-Time Monitoring: Built-in LCD display and companion app provide live status, charge progress, and battery health analytics.
• Safety Certifications: CE, FCC, and RoHS compliant with over-current, short-circuit, and surge protection.

Technical Specifications

• Input Voltage: AC 100-240V, 50/60 Hz (2000W max)
• Output Voltage: 26.1V DC per channel
• Charging Channels: 8 independent slots
• Max Charging Current: 10A per channel
• Battery Compatibility: DJI TB60, TB65, and TB70 series intelligent batteries
• Dimensions: 420 x 320 x 180 mm (16.5 x 12.6 x 7.1 in)
• Weight: 12.5 kg (27.6 lbs)
• Operating Temperature: -10°C to 40°C (14°F to 104°F)
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Protection Rating: IP54 (dust & splash resistant)

Benefits

• Maximized Productivity: Reduce downtime with rapid charging cycles, enabling more flights per day for mapping, inspection, or logistics.
• Lower Total Cost of Ownership: Prolong battery life by up to 30% through intelligent charge management, reducing replacement frequency.
• Uninterrupted Field Operations: Hot-swappable trays and multi-power source support keep your fleet mission-ready in remote locations.
• Enhanced Safety: Automated thermal regulation and fault detection eliminate manual monitoring risks, protecting both equipment and personnel.
• Scalable for Growth: Modular stacking design adapts to expanding fleets without infrastructure overhaul, perfect for enterprise growth.
